scope of application
● molded case circuit breaker integrates gm6-160 of beijing people's electric co., ltd. all the characteristics of the high quality, high reliability and simple, is a real simple practical molded case circuit breaker。reduced size, but still to ensure superior performance and reliability, and is higher than all the similar circuit breaker products on the market than the performance of the size, can provide users with more space for the cable wiring, decrease the size of switchgear altitude 2000 m and below, above 2000 m need to let use reduction.other special requirement, please contact the manufacturer。
using the environment
altitude 2000 m and below, up from 2000 m to let use reduction.other special requirement, please contact the manufacturer;
● anti-corrosion ability under the influence of humid air (type)①;
● resistant to salt spray mist effect (three);
● anti-corrosion ability under the influence of mold (type);
● in the absence of explosion danger of medium, and medium without enough to corrosive action on metals, and damage the insulation of conductive dust and gas。
note: (1) three products need special customized, please indicate th。
execution standard
● iec 60947-2
● gb 14048.2
the main features
● gm6-160 type circuit breaker can be used for 50/60 hz ac tn, tt, it power distribution system and distributed photovoltaic junction box;
● all is 50 ℃ not let (except shell frame of 125 a, 125);
● the series circuit breaker reliable contact indication and isolation function;
● gm6-160 type circuit breaker is only 68 mm thick, with light volume, the performance of the highest volume ratio, can provide users with more space for the cable wiring, decrease the size of switchgear;
● gm6-160 type circuit breaker arcing cover can be equipped with zero, truly achieve zero flashover;
● configuration is simple, convenient customer selection and order;setting in advance before they leave the thermomagnetic tripping unit specifications, avoid setting error when installation, convenience for the plate of factory workers and customers in the future of the spare parts to replace.simple installation, set up quickly。
● accessories full range;
● double insulation;
● reliable operation, light;
● multiple installation, can be horizontal, vertical, lie on your side of the breaker。
model establishment and meaning
technical parameters
